Porter
DentalSilhouette System
Porter — Silhouette System
Silhouette 2 Breathing System
Non-coaxial breathing system with colour-coded sizer masks. Uses 22mm standard fittings and can be adapted to work with most flowmeter systems.
Key Features
- Non-coaxial design with separate fresh gas and vacuum tubes
- 22mm standard fittings throughout — wide compatibility
- Colour-coded sizer masks in 4 sizes included
- Available in packs of 12 and 24 masks in each size
- Latex free
- Compatible with Accutron and Porter flowmeter systems
The Silhouette 2 is a non-coaxial (separate fresh gas and vacuum tubes) breathing system that uses 22mm standard fittings throughout, making it compatible with a wide range of flowmeter systems. The kit includes colour-coded sizer masks in four sizes (paediatric, adult small, medium, and large) to ensure a proper fit for all patients. The system uses a different scavenging approach to the Porter Brown coaxial system, with separate fresh gas and vacuum lines.
Price
Valid 1 Sept 2026 – 1 Sept 2027
£62.00ex VAT
Part Number
SIL2-RETRO-PKG
Need advice? Speak to our specialist team.
Technical Specifications
- Type
- Non-coaxial breathing system
- Dimensions
- Four nasal mask sizes: Pediatric 6.25 x 4.52 x 2.73cm (2.46" x 1.78" x 1.08"), Small 6.02 x 4.98 x 2.95cm (2.37" x 1.96" x 1.16"), Medium 6.55 x 5.69 x 4.05cm (2.58" x 2.24" x 1.60"), Large 6.47 x 6.02 x 4.32cm (2.55" x 2.37" x 1.70")
- Weight
- 0.04–0.05 kg per mask (0.09–0.10 lbs); kit weight varies by contents
- Fittings
- 22mm standard
- Mask Sizes
- Paediatric, Adult Small, Medium, Large
- Tubing
- Fresh gas + vacuum (separate)
- Common accessories
- Fresh gas and vacuum tubing (B-5581-000), cannula adapter (B-5603-000)
